Apex 5.12kW Lithium Battery – 100A IP20 Battery
Original price was: ₨ 240,000.₨ 235,000Current price is: ₨ 235,000.
Key Features
- 5.22kWh lithium battery capacity
- LiFePO4 (Lithium Iron Phosphate) technology
- 51.2V nominal voltage
- 102Ah nominal capacity
- Up to 8,000 battery cycles (80% DoD, 25°C, 0.5C, 60% EOL)
- 50A charging current
- 100A discharge current
- 2.56kW charging power
- 5.12kW discharge power
- LED status indicator
- CAN, RS485 & RS232 communication
- Wall mount or floor stand installation
- IP66 protection rating
- Expandable up to 15 batteries in parallel
- CE & UN38.3 certified
100 in stock
Apex 5.12kWh LiFePO4 Lithium Battery
Short Introduction
The Apex 5.12kWh LiFePO4 Lithium Battery is a reliable energy storage solution designed for residential and commercial solar systems. Featuring advanced Lithium Iron Phosphate (LiFePO4) technology, it provides long battery life, efficient performance, and flexible installation options for hybrid and off-grid solar applications.
Product Highlights
- 5.22kWh battery energy
- 51.2V nominal voltage
- 102Ah battery capacity
- Advanced LiFePO4 battery technology
- Up to 8,000 battery cycles
- Floor-standing or wall-mounted installation
- CAN, RS485 & RS232 communication
- IP66 weather-resistant protection
- Expandable up to 15 batteries in parallel
- CE & UN38.3 certified
Product Description
The Apex 5220 Pro Lithium Battery is engineered to deliver dependable solar energy storage for homes, offices, and commercial applications. With a 5.22kWh energy capacity, it stores solar power efficiently and provides reliable backup when needed.
Built using LiFePO4 (Lithium Iron Phosphate) cell technology, the battery offers excellent safety, durability, and long service life. It supports up to 8,000 charge cycles under specified operating conditions, making it a practical choice for long-term energy storage.
The battery features CAN, RS485, and RS232 communication interfaces for compatibility with supported hybrid inverters and battery management systems. Its IP66-rated enclosure provides enhanced protection against dust and water, while the option for wall-mounted or floor-standing installation offers greater installation flexibility.
For larger energy storage requirements, the Apex 5220 Pro supports up to 15 batteries connected in parallel, allowing the system to expand as power demands grow.
Technical Specifications
| Specification | Details |
|---|---|
| Model | Apex 5220 Pro |
| Battery Technology | LiFePO4 (Lithium Iron Phosphate) |
| Battery Energy | 5.22kWh |
| Nominal Voltage | 51.2V DC |
| Nominal Capacity | 102Ah |
| Charge Current | 50A |
| Charge Power | 2.56kW |
| Discharge Current | 100A |
| Discharge Power | 5.12kW |
| Short Circuit Current | 350A |
| Display | LED Indicator |
| Communication | CAN, RS485, RS232 |
| Installation | Floor Stand or Wall Mount |
| Dimensions | 650 × 420 × 138 mm |
| Weight | 47kg |
| Operating Temperature | Charge: 0°C to 55°C / Discharge: -20°C to 55°C |
| Operating & Storage Humidity | ≤95% RH |
| Maximum Operating Altitude | ≤2000m |
| IP Rating | IP66 |
| Cycle Life | 8,000 Cycles @ 80% DoD / 25°C / 0.5C, 60% EOL |
| Scalability | Maximum 15 batteries in parallel |
| Certifications | CE, UN38.3 |
Applications
The Apex 5220 Pro is suitable for:
- Residential solar energy storage
- Hybrid solar systems
- Off-grid solar installations
- Backup power systems
- Commercial solar projects
- Small industrial energy storage
Compatibility
The battery supports CAN, RS485, and RS232 communication protocols, making it compatible with supported hybrid inverters and energy management systems that use these communication interfaces.
Warranty
Warranty information is not provided in the official manufacturer datasheet.
Why Choose the Apex 5220 Pro 5.22kWh LiFePO4 Lithium Battery?
The Apex 5220 Pro 5.22kWh Lithium Battery combines reliable LiFePO4 technology, long cycle life, IP66 protection, and flexible installation options in a compact design. Its support for parallel expansion up to 15 batteries and compatibility with modern hybrid solar systems make it an excellent choice for residential and commercial energy storage applications in Pakistan.
